Produktgruppe: CD Geräte
East Sound CD-Player CD-E5 European Edition mit analogem Klangbild in Dinslaken vorführbereit!!
01.12.2006
Neu!
Ab sofort führen wir die fantastischen High-End CD-Player von East Sound
mit ihrem überragenden Preis/Leistungsverhältnis!!!
Sie werden staunen, wie "analog" diese CD-Player klingen.
SPECIFICATIONS:
24 BIT, 128 TIMES OVERSAMPLING
FREQUENCY RESPONSE: 20Hz – 20KHz +/-0.2db
DYNAMIC RANGE: 95db
S/N RATIO: 100db
THD: < 0.01% (UNBALANCED); < 0.005% (BALANCED)
CHANNEL SEPERATION: 96db
OUTPUT VOLTAGE: 2Vrms (UNBALANCED); 4Vrms (BALANCED)
DIGITAL OUTPUT (COAXIAL):
S/PDIP (SONY / PHILIPS) 6MB/s 80MHz
DIGITAL OUTPUT (OPTICAL)
JEITA CP-1201 TOS-LINK 6MB/s
FUSE TYPE: 1.5A 250V
POWER CONSUMPTION: 18VA
DIMENSION: 430 x 355 x 110mm LxWxH
Wir sind autorisierter East Sound - Händler.
Hörprobe nach Terminvereinbarung erwünscht, wir freuen uns auf Ihren Besuch.
Weitere Infos auch gerne telefonisch.
-------------------------------------------------------------------------------------
Weitere Infos vorerst noch in Englisch:
TRUE BALANCED ANALOG OUTPUT STAGE: THE TOUCHING AND ELEGANT SOUND COME FROM THE INDIVIDUAL UNIQUE (EXCLUSIVE BALANCED TUNING TECHNOLOGY BY EASTSOUND) ANALOG OUTPUT CIRCUITS. ISOLATED PURE CLASS A FULL BALANCED OUTPUT CIRCUIT IN RCA OUTPUT ROUTE AND FULL BALANCED NE5534 BASED OUTPUT IN XLR OUTPUT ROUTE. HIGH-END CAPACITORS (e.g. WIMA BLACK BOX) & SECRET FORMULATED NON-MAGNETIC INDUCTORS EMPLOYED IN VARIOUS STAGES.
TCCO / TCXO (TEMPERATURE COMPENSATED CRYSTAL OSCILLATOR) CLOCK SYSTEM: AS REFERENCE FREQUENCY COUPLED BY ADAPTATION OF CLOCK DISTRIBUTION SYSTEM (CDS). TCCO / TCXO IS AN EXTREMELY HIGH-END AND EXPENSIVE CLOCK SYSTEM WITH BETTER THAN 5ppm (part-per-million) ACCURACY - 200 FOLD IMPROVEMENT OVER STANDARD OSCILLATORS USED IN MOST CD PLAYERS. EXTREME HIGH-END CD PLAYERS INCORPORATED WITH TCCO / TCXO CLOCK SYSTEM INCLUDE: MARK LEVINSON 390S, WADIA 270, 270SE TRANSPORT SYSTEM AND WADIA 27iX DECODING COMPUTER.
CLOCK DISTRIBUTION SYSTEM (CDS): THE FIRST IN CHINA THAT EMPLOYS THIS HIGH-END TECHNIQUE - EACH COMPONENT REQUIRING THE REFERENCE FREQUENCY IS EQUIPPED WITH AN INDEPENDENT PATHWAY, WITH PRECISE IMP MATCHING. DIGITAL SIGNAL REFLECTION INTERFERENCE TO ANALOG SIGNAL CIRCUITS ARE BANNED. TCCO / TCXO + CDS HAVE TURNED E5 INTO A SUPREME ACCURATE AND HIGH PERFORMANCE DIGITAL TRANSPORT AS WELL.
HEAVY DUTY DESIGN: NET WEIGHT OVER 23 lbs; 13mm THICK ANODIZED ALUMINUM FRONT PANEL AND SIDE PANELS WITH THICK ZINC PLATED STEEL AS UNDER PLATE - ALL PROVIDE EXCELLENT STABILITY TO THE TRANSPORT SYSTEM WITH ANTI-ELECTROMAGNETIC INTERFERENCE CAPABILITY.
PURE CLASS A RCA ANALOG OUTPUT STAGE: THE TOUCHING AND ELEGANT SOUND COME FROM THE INDIVIDUAL UNIQUE (EXCLUSIVE BALANCED TUNING TECHNOLOGY BY EASTSOUND) ANALOG OUTPUT CIRCUIT. HIGH-END CAPACITORS (e.g. WIMA BLACK BOX) & SECRET FORMULATED NON-MAGNETIC INDUCTORS EMPLOYED IN VARIOUS STAGES.
CRYSTAL CLEAR ELECTRIC SUPPLY (CCES) TECHNIQUE: 10 SETS OF ISOLATED STABLE VOLTAGE SUPPLY EMPLOYING THE UNIQUE CCES TECHNIQUE TO ALL DIGITAL AND ANALOG SIGNAL PATHWAYS - COMPLETELY TACKLE CROSS INTERFERENCE.
TOTAL SEPARATED BUFFERED CIRCUIT DESIGN: THE NEW DEVELOPED CURRENT SERVO CIRCUIT AS OPPOSITE TO THE TRADITIONAL DC SERVO CIRCUIT SYSTEM - GREAT IMPROVEMENT ON LOW FREQUENCY EXTENSION AND RESOLUTION.
CRYSTAL 4390 DAC: A FAMOUS MUSICAL DAC WITH ULTRA HIGH S/N RATIO EMPLOYED IN HIGH-END CD PLAYERS SUCH AS GAMUT CD1 MKII AND MERIDIAN 508.24. AUDIO ENGINEERS HAD CLAIMED THAT CRYSTAL 4390 IS OF A SUPERB PERFORMANCE STANDARD AND THE POTENTIAL OF THIS DAC HAS NOT BEEN FULLY EXTRACTED SO FAR.
SONIC PERFORMANCE
A TOTAL UPGRADE ON SOUND PERFORMANCE WELL ABOVE THE STRENGTHS OF EASTSOUND"S PREVIOUS LOWER MODEL E3 CD PLAYER. THE MODEL NUMBER DESIGN HAS AN INTENTION TO CONVEY THE LEVEL OF SONIC IMPROVEMENTS OVER THE PREVIOUS MODEL
E5 OFFERS WONDERFUL RESOLUTION OF LOW LEVEL MUSICAL DETAILS WITH SUBSTANTIAL EXTENSION OF LOW FREQUENCY AND HIGH FREQUENCY CLARITY; THE MID-RANGE HAS A SENSE OF NATURAL AND MUSICAL WARMTH COUPLED WITH A KIND OF UNIQUE TOUCHING EMOTION THAT IS HARD TO FORGET.
UNLIKE SOME TUBE CD PLAYERS, E5 HAS ALL THE SMOOTH PASSAGES YOU CAN EXPECT FROM THEM WHILE MAINTAINING SPEED AND RESOLUTION. SLOW AND SYRUPY FEELINGS ARE NOT PRESENT. E5 SHOULD BE CONSIDERED TO BE A WONDERFUL BLEND WITH ALL THE BENEFITS WE CAN EXPECT FROM HIGH-END TUBE CD PLAYERS AND TRANSISTOR CD PLAYERS.
ALL THESE WONDERFUL PERFORMANCES ARE COUPLED WITH AN UNFORGETTABLE SOUND STAGE - A BEAUTIFUL SENSE OF DEPTH AND WIDTH. THAT IS THE REAL SOUND FOR REMEMBERANCE AND THAT IS THE REAL SOUND FROM THE EAST. . . . . . .
ANATOMY
GOLD PLATED OEM RCA, XLR OUTPUT JACKS AND DIGITAL OUTPUT JACKS.
SPECIAL HAND-MADE TOROIDAL TRANSFORMER WITH NO WELDING POINT OUTLETS.
3mm EXTRA ZINC PLATED STEEL BOARD UNDER THE TRANSFORMER: AGAINST ELECTROMAGNETIC INTERFERENCE.
POWER SUPPLY BOARD EMPLOYS 4 x WIMA BLACK BOX - REVEALS THE GREAT EMPHASIS ON POWER SUPPLY.
CIRCUIT BOARDS: MADE OF SECRET FORMULATED MATERIAL. A MAIN SECRET BEING THE ADDITION RATIO AND ADDITION SEQUENCE OF UV PROTECTION FACTORS.
LEFT SIDE: THE HIGH-END TCCO / TCXO (TEMPERATURE COMPENSATED CLOCK OSCILLATOR) CLOCK SYSTEM;
RIGHT SIDE: SPECIAL DIGITAL INTERFACE IC PROGRAMMED BY EASTSOUND"S OWN SOFTWARE IMPLEMENTATION.
LPF SECTION: 2 x WIMA BLACK BOX + SECRET FORMULATED NON-MAGNETIC INDUCTORS.
PHILIPS VAM TRANSPORT MOUNTED ON A 5mm THICK ALUMINUM PLATE: STABILITY OF TRANSPORT MECHANISM GREATLY ENHANCED.
