Produktgruppe: CD Geräte
East Sound CD-E5 Platinum Reference Edition!!!
09.10.2008
East Sound CD-E5 Platinum Reference Edition:
Neues Topmodell von East Sound mit neuem nochmals verbessertem Konzept,
neuem Wandler- und Filterbaustein, superschnellen Gleichrichterdioden,
größeren und verbesserten Siebkapazitäten, Neutrik Ausgangsbuchsen usw....
(siehe englische Beschreibung)
Vereinbaren Sie mit uns einen persönlichen Hörtermin in ruhiger Atmosphäre.
Wir freuen uns auf Ihren Besuch.
Mehr Informationen auch gerne telefonisch:
02064-609498
-------------------------------
Händleranfragen willkommen!
-------------------------------
Beschreibung vorerst noch in Englisch:
TECHNICAL:
FORMAT: 24 BIT/ 192Khz
SAMPLING FREQUENCY: 8Hz to 192KHz
FREQUENCY RESPONSE: 20Hz – 20KHz +/-0.2db
OUTPUT IMPEDENCE: 15ohms
DYNAMIC RANGE: 98db
S/N RATIO: 102db
THD: < 0.01% (UNBALANCED); < 0.005% (BALANCED)
CHANNEL SEPERATION: 97db
OUTPUT VOLTAGE: 2Vrms (UNBALANCED); 4Vrms (BALANCED)
DIGITAL OUTPUT (COAXIAL): S/PDIP (SONY / PHILIPS), 6MB/s, 80MHz
DIGITAL OUTPUT (OPTICAL): JEITA CP-1201 TOS-LINK, 6MB/s
POWER CONSUMPTION: 22VA
Voltage Standard: 230V
DIMENSION: 430 x 355 x 110mm LxWxH
Weight: 13Kg
ADVANCEMENTS OVER E5 SIGNATURE EDITION:
1. Massive 27200uF noVer filter capacitance (19200uf in signature edition).
2. Fast recovery diodes (Philips, Netherlands) for rectification.
3. New power stabilization modules.
4. Stable voltage supply to mainboard increased from 5V to 8V.
5. Analog Devices 797 x 2 for analog filter.
6. Swiss made Neutrik output connectors.
7. AES digital output with Swiss made Neutrik connector..
8. Sophisticated digital output stage employing special sma connection bypassing printed circuit board - making it to be an ultimate high-end cd transport as well..
9. Ultimate high-end parts including Green Wima capacitors (Germany made), Black Box capacitors (Germany made), ERO capacitors (Germany made), EVOX capacitors (Germany made), Elna for Audio, Philips . . . .
10. New modified fully differential voltage output 24bit / 192Khz DAC.
11. Crazy Expensive Platinum wire employed for the noble and precise sonic presentation.
SONIC PERFORMANCE OF PLATINUM REFERENCE EDITION:
Completely different from the Signature edition, the platinum reference edition is of precise, neutral and transparent sonic characters that can rewrite the reference standard for a highest performance red book cd player.
Extension and resolution in bass and treble areas has achieved the maximum possible standard that can reveal every minute details coupled with silky smoothness.
Presented with stunning micro and macro dynamics while achieving the noble natural mid frequency with unbelievable density ever.
COMMON POINTS RETAINED FROM THE SIGNATURE EDITION:
PHILIPS MACHANISM: MOUNTED ON A 5mm THICK ALUMINUM PLATE: OPTIMUM ENHANCEMENT ON STABILITY.
G9 PRO DIGITAL SERVO SYSTEM: AN EXTREME HIGH-END DESIGN TO PROVIDE ULTIMATE ACCURACY IN READING MACHANISM. ONLY AVAILABLE IN THIS LATEST PRIME VERSION. WITH CRAZY EXPENSIVE PARTS SUCH AS VISHAY RESISTOR (FOUND ON US$30000- RANGE MARK LEVINSON OR ORPHEUS EQUIPMENT), EVO CAPS FROM GERMANY, RIFA CAPS FROM SWISS; SIEMENS AND GREEN WIMA CAPS FROM GERMANY . . .
TRUE BALANCED ANALOG OUTPUT STAGE: ISOLATED PURE CLASS A FULL BALANCED OUTPUT CIRCUIT IN RCA OUTPUT ROUTE AND FULL BALANCED TEXAS INSTRUMENTS NE5534 BASED OUTPUT IN XLR OUTPUT ROUTE. HIGH-END CAPACITORS (e.g. WIMA BLACK BOX) & SECRET FORMULATED NON-MAGNETIC INDUCTORS EMPLOYED IN VARIOUS STAGES.
OVER 30 MODELS OF EXTREME HIGH-END WIRES EMPLOYED: IN ORDER TO ACHIEVE THE FINAL SOUND, VARIOUS EXTREME QUALITY HIGH-END AUDIO WIRES SUCH AS CARDAS, AMPEX, AUDIOQUEST, TARA LABS, KIMBER . . . . . . ETC ARE EMPLOYED. ULTIMATE EXPENSIVE ONE SUCH AS "SKY" AND "THE ZERO" ARE PRESENT.
TCCO / TCXO (TEMPERATURE COMPENSATED CRYSTAL OSCILLATOR) CLOCK SYSTEM: AS REFERENCE FREQUENCY COUPLED BY ADAPTATION OF CLOCK DISTRIBUTION SYSTEM (CDS). TCCO / TCXO IS AN EXTREMELY HIGH-END AND EXPENSIVE CLOCK SYSTEM WITH BETTER THAN 5ppm (part-per-million) ACCURACY - 200 FOLD IMPROVEMENT OVER STANDARD OSCILLATORS USED IN MOST CD PLAYERS. EXTREME HIGH-END CD PLAYERS INCORPORATED WITH TCCO / TCXO CLOCK SYSTEM INCLUDE: MARK LEVINSON 390S, WADIA 270, 270SE TRANSPORT SYSTEM AND WADIA 27iX DECODING COMPUTER.
CLOCK DISTRIBUTION SYSTEM (CDS): THE FIRST IN CHINA THAT EMPLOYS THIS HIGH-END TECHNIQUE - EACH COMPONENT REQUIRING THE REFERENCE FREQUENCY IS EQUIPPED WITH AN INDEPENDENT PATHWAY, WITH PRECISE IMP MATCHING. DIGITAL SIGNAL REFLECTION INTERFERENCE TO ANALOG SIGNAL CIRCUITS ARE BANNED. TCCO / TCXO + CDS HAVE TURNED E5 INTO A SUPREME ACCURATE AND HIGH PERFORMANCE DIGITAL TRANSPORT AS WELL.
HEAVY DUTY DESIGN: NET WEIGHT OVER 25 lbs; 13mm THICK ANODIZED ALUMINUM FRONT PANEL AND SIDE PANELS WITH THICK ZINC PLATED STEEL AS UNDER PLATE - ALL PROVIDE EXCELLENT STABILITY TO THE TRANSPORT SYSTEM WITH ANTI-ELECTROMAGNETIC INTERFERENCE CAPABILITY.
CRYSTAL CLEAR ELECTRIC SUPPLY (CCES) TECHNIQUE: 10 SETS OF ISOLATED STABLE VOLTAGE SUPPLY EMPLOYING THE UNIQUE CCES TECHNIQUE TO ALL DIGITAL AND ANALOG SIGNAL PATHWAYS - COMPLETELY TACKLE CROSS INTERFERENCE. SPEICAL HANDMADE MASSIVE TOROIDAL TRANSFORMER WITH NO WELDING POINT OUTLETS. THERE IS A 3mm EXTRA ZINC PLATED STEEL BOARD UNDER THE TRANSFORMER: AGAINST ELECTROMAGNETIC INTERFERENCE. POWER SUPPLY BOARD EMPLOYS WIMA BLACK BOX - REVEALS THE GREAT EMPHASIS ON POWER SUPPLY.
TOTAL SEPARATED BUFFERED CIRCUIT DESIGN: THE NEW DEVELOPED CURRENT SERVO CIRCUIT AS OPPOSITE TO THE TRADITIONAL DC SERVO CIRCUIT SYSTEM - GREAT IMPROVEMENT ON LOW FREQUENCY EXTENSION AND RESOLUTION.
